Plug two male L5-30P plugs into two L5-30R receptacles
Y Splitter – L14-30P Plug to Two L5-30R Connectors, 10 Foot
Email [email protected] for quantity discounts or a quote
Overview
Splitter power cord allows you to plug two NEMA L5-30P male plugs into a single NEMA L14-30P twist lock cable. Cable has a 10 foot main branch on the L14-30P side, and two 2 foot L5-30R legs. Rated for 30 amps, 250V.
Features
- NEMA L14-30P plug to 2x L5-30R connectors
- 10 Foot Length
- SJT jacket
- Rated for 30 Amps and 250 Volts
- 10/3 AWG wire
Specifications
| Plug | L14-30P |
| Connector | L5-30R x 2 |
| Voltage | 250V |
| Amperes | 30A |
| Length | 10′ + 2′ |
| Jacket Type | 10/3 SJT |
| Color | Black |
* SJT jacket is thicker but less flexible compared to the SVT jacket.
UL and CSA Listed, ROHS approved
